1700MHz to 2200MHz High-Linearity,
SPI-Controlled DVGA with Integrated Loopback Mixer
Direct-Conversion Base-Station
Transmitter
The MAX2058/MAX2059 are designed to interface
directly with Maxim ’s direct-conversion quadrature
modulators and high-speed DACs to provide a com-
plete solution for GSM/EDGE base-station transmitter
together with the MAX2021/MAX2022/MAX2023 direct-
conversion modulators/demodulators, the MAX5873
dual-channel DAC, and the MAX4395 quad amplifier,
form an ideal total transmitter lineup. This overall sys-
tem is highly efficient and low cost, while maintaining
high linearity and low-noise performance.
applications. See Figure 2. The MAX2058/MAX2059,
Typical Application Circuit
V CC
RF INPUT
C22
C19
C17
C18
R3
R1
C23
LO INPUT
T1
40
39
38
37
36
35
34
33
32
31
V CC
R4
LO+
1
5-BIT ATTENUATOR
30
GND
V CC
LO-
VCCLB
2
3
A
29
28
VCCBIAS1
AMPIN
C15
C14
C16
C1
C2
LBOUT
4
MAX2059
27
VCCAMP
V CC
LBOUT
C3
LB_EN
5
DRIVER AMP
26 GND
C12
C13
DATA
6
25
GND
CLK
CS
7
8
SPI
24
23
GND
AMPOUT
V CC
C4
C5
VCCLOGIC
GND
9
10
5-BIT ATTENUATOR
B
E.P.
22
21
GND
VCCBIAS2
C11
C20
V CC
C9
C10
11
12
13
14
15
16
17
18
19
20
R2
C24
RF OUTPUT
C6
C21
C8
C7
